1. Model Numbers

3. Key Features & Selling Points

YN-LP1000IP

1. IP65 Weatherproof Rating — Sealed housing protects against rain and dust, suitable for outdoor stages, events, and architectural installations.
2. 850W High-Output LED Engine — 22,000 lm luminous flux with 20,000-hour lifespan, delivering bright, consistent output with minimal maintenance.
3. Optional Ra > 96 High-CRI LED — Beyond standard Ra>70 and high-CRI Ra>90 modes, an optional Ra>96 LED configuration is available for broadcast-critical applications.
4. Dynamic Effects Wheel — Built-in effects wheel simulates flickering flames, flowing water, and other animated patterns, adding creative atmosphere without extra fixtures.
5. Dual Rotating Gobo Wheels — 7 interchangeable gobos + 8 fixed gobos + white spot, enabling rich pattern projection and seamless gobo morphing.
6. Dual Prism System — Rotating 4-facet prism + 6-facet prism for beam multiplication and dynamic mid-air effects.
7. Precision 4-Blade Framing (120°) — Independently controlled shutter blades with 120° rotation for accurate beam shaping in theatrical and architectural applications.
8. 5-Phase Motors with Magnetic Encoding — Ultra-smooth, precise, and silent pan/tilt movement with accurate position feedback and auto-calibration.
9. Full CMY + Independent CTO — Rich color mixing from CMY system plus independent linear CTO (2500K–7000K) for precise color temperature control.
10. Multiple Control Modes — DMX512 / RDM / Auto / Master-Slave / Sound-Activated with 36/42/60 channel modes.

YN-LP1200IP

Includes all features above, plus:

1. 1000W High-Power LED Module — 18% more optical power than the 1000W model, delivering superior throw distance and luminous intensity for large venues
2. 1120W Total Power — Designed for large-scale outdoor stages, concert tours, and high-bay architectural lighting where maximum output is required.
3. Same Feature Set, Higher Output — Identical optical system (effects wheel, dual gobos, dual prism, framing) in a higher-power configuration — consistent creative palette across the series.
