Available Variants: 371W / 420W / 460W

Specifications

No.	Item	Parameters
1	Voltage	AC 90–235V, 50–60Hz (Wide Voltage)
2	Driver	650W Wide-Voltage Driver
3	Light Source	Imported Philips Lamp — 371W / 420W / 460W
4	Color Temperature	8000K
5	Color System	Color wheel: 11 colors + white open
6	Fixed Gobo System	Fixed gobo wheel: 14 fixed gobos + 1 white open
7	Rotating Gobo System	Rotating gobo wheel: 9 gobos + 1 white open
8	Focus System	Electronic focus
9	Strobe	Dual-motor independent strobe, 0.5–20 flashes/sec, adjustable speed
10	Pan/Tilt Motor	3-phase motors for high-speed stability and precise positioning
11	Dimming	0–100% linear dimming, smooth and flicker-free
12	Beam Angle	2°–40° (motorized zoom)
13	DMX Channels	16 channels or 20 channels (selectable)
14	Lens Diameter	135mm
15	Waterproof Rating	IP66
16	Control Modes	DMX512, Standalone, Master-Slave, RDM (Remote Device Management); address code configurable remotely via large-format controllers
17	Prism System	8-facet prism (configurable per customer requirement)
18	Display	LCD display, 180° rotatable for flexible mounting orientation
19	Pan/Tilt Performance	High-precision 3-phase motors, accurate positioning, smooth movement, auto position calibration
20	Pan	540° rotation, 8/16-bit resolution with fine adjustment
21	Tilt	270° rotation, 8/16-bit resolution with fine adjustment
22	Cooling System	Cast aluminum + plastic housing, whole-body convection cooling
23	Installation	Floor standing / Hanging (truss mount)
24	Dimensions & Weight	Fixture: 430 × 260 × 630 mm (L×W×H); Carton: 410 × 490 × 770 mm; Net Weight: 26 kg; Gross Weight: 32 kg

Light Source Options (Variant Comparison)

Variant	Lamp Power	Lamp Brand	Color Temp	Beam Angle	Waterproof
YN-BSWP-371	371W	Philips	8000K	2°–40°	IP66
YN-BSWP-420	420W	Philips	8000K	2°–40°	IP66
YN-BSWP-460	460W	Philips	8000K	2°–40°	IP66

Product Description
Masterpiece of Engineering — Beam / Spot / Wash All in One.
With its premium exterior and massive light output, this waterproof 3-in-1 moving head delivers a thick,
punchy beam alongside crisp gobo projection and smooth color washing — all in a single fixture.
Every aspect, from optics and structure to industrial design, meets the highest standards.
Featuring cutting-edge high-brightness Philips lamp technology, advanced optical engineering,
and rigorous industrial design, it ensures perfect execution of every lighting design concept.
Built with an IP66-rated cast aluminum housing, it performs reliably in any outdoor environment.
