1000W IP65 Outdoor Waterproof LED Strobe Light

  • PID:YN-ST1000IP
  • Wechat:13435630187
  • Phone: 13435630187
  • Tel: 13435630187
  • Email: business@yinuolight.com
  • FEEDBACK

Product Parameters

Parameter Specification
Input Voltage AC 100–240V ~ 50/60Hz
Power Consumption 1000W
Strobe Panel LED 576 × 5050 0.5W RGB 3-in-1 LEDs, 16 segments (2 × 8)
Strobe Tube LED 144 × 3535 5W 6500K White LEDs, 8 segments
Tilt Angle (Y-axis) 185°
Channel Modes 11CH / 15CH / 59CH / 71CH
Display Illuminated Graphic LCD Display
Control Protocol DMX-512, RDM
Dimming Modes 4 dimming curves
Built-in Programs Multiple built-in effect programs
Control Methods Standard DMX512, RDM, Sound Active, Auto Run, Master/Slave
Cooling System Temperature-controlled fan cooling with overheat protection
Waterproof Rating IP65
Signal Connector Seetronic IP65 XLR 5-pin / 3-pin Input & Output
Power Connector Seetronic PowerCON TRUE1 Input & Output
Dimensions (L × W × H) 51.5 × 13.6 × 34 cm
Package Dimensions (L × W × H) 70 × 43 × 23 cm
Net Weight 12 kg
Gross Weight 12.45 kg
Packing Quantity 1 pc/carton


Key Selling Points

  1. Dual LED System — RGB Color + Pure White Strobe Combines 576 RGB 3-in-1 LEDs for vibrant color washes with 144 high-power 6500K white LEDs for blinding strobe effects, delivering both atmosphere and impact in one fixture.
  2. Segmented Independent Control RGB panel divided into 16 segments (2×8) and white strobe tubes into 8 segments, enabling pixel-style chases, wave effects, and dynamic patterns when used in 59CH or 71CH mode.
  3. IP65 Outdoor-Rated Construction Fully sealed housing with Seetronic IP65 XLR and PowerCON TRUE1 connectors, engineered for reliable operation in rain, dust, and harsh outdoor environments.
  4. 185° Motorized Tilt Wide-range Y-axis movement allows precise beam direction adjustment, covering stages, audiences, and architectural surfaces from a single rig point.
  5. Four Channel Modes for Flexibility 11CH / 15CH for basic control, 59CH / 71CH for full segment-level programming — adapts to any console capability and show complexity.
  6. Excellent Sound-Active Performance High-sensitivity built-in microphone syncs strobe pulses and color effects to music beats with exceptional responsiveness, ideal for DJ sets and live events.
  7. Professional-Grade Connectors Seetronic PowerCON TRUE1 power in/out and IP65 XLR signal in/out support daisy-chaining multiple fixtures, reducing cable clutter and simplifying rigging.
  8. Intelligent Thermal Management Temperature-controlled cooling with automatic overheat protection ensures stable output and extends LED lifespan during long-duration events.

Application Scenarios

  • Music Festivals & Outdoor Concerts — IP65 rating withstands weather; high-output white strobe and RGB panel create massive stage impact.
  • Live Stage & Theater — 185° tilt and segmented control deliver precise, dynamic lighting cues for performances.
  • Bars & Nightclubs — Sound-active mode syncs to DJ beats; RGB color washes set the mood, white strobes drive the energy.
  • Lounges & Fine Dining Bars (清吧) — Adjustable dimming curves and built-in programs provide subtle ambient lighting without overwhelming the space.
  • KTV Private Rooms — Compact form factor and auto-run programs bring club-level effects to private entertainment spaces.
  • Corporate Events & Product Launches — Reliable outdoor/indoor dual-use design with professional DMX/RDM control for production teams.
  • Architectural & Landscape Lighting — IP65 housing and RGB color capability support facade illumination and outdoor decorative installations.
